3D Scanner Comparison

Specification Comparison

Hide same item

MIRACO Plus

$1,979.00

BUY NOW >

MIRACO(Pro)

$1,143.00

BUY NOW >

POP 3 Plus

$611.00

BUY NOW >

Scanning Type

Standalone Handheld and Desktop, and photogrammetric metrology

Standalone Handheld and Desktop

Handheld and Desktop

Technology

Quad-camera Infrared Structured Light with Optical zoom, and Ultra-resolution photogrammetric metrology

Quad-camera Infrared Structured Light

Scannable Object Size

Small to Large

Medium

Single-frame Precision, up to*

0.02 mm

0.04 mm

Single-frame Accuracy, up to*

0.04 mm

0.05 mm

0.08 mm

Photogrammetric Length Accuracy

0.02 mm + 0.05 mm × L (m). L is the maximum measuring distance in meters.

N/A

Fused Point Distance, up to

0.05 mm

Working Distance

100 - 1000 mm

100 ~ 1000 mm

150 ~ 400 mm

Single Capture Area at Nearest Distance

28 x 53 mm at 100 mm

28 × 53 mm at 100 mm

61 × 68 mm at 150 mm

Single Capture Area at Furthest Distance

975 x 775 mm at 1000 mm

975 × 775 mm at 1000 mm

244 × 180 mm at 400 mm

Angular Field of View (H x W)

Near 40 × 30°, Far 56 × 42°

40 × 25°

Minimum Scan Volume

10 x 10 x 10 mm

10 × 10 × 10 mm

20 × 20 × 20 mm

Maximum Scan Volume

4 × 4 × 4 m

2 × 2 × 2 m

Scanning Speed, up to

20 fps

15 fps

18 fps

Depth-camera Resolution,up to

2 Megapixels

1 Megapixel

RGB-camera Resolution

48 Megapixels

1 Megapixel

Color Scanning

Yes

Scanning Mode

Continuous, Single-shot

N/A

Tracking Methods

Feature, Marker, Global Marker

Outdoor Scanning*

Yes

3D Light Source*

Class 1 Infrared Light

Infrared Fill Lights*

8 Infrared LEDs

4 Infrared LEDs

White Flash LEDs*

2 White Flash LEDs

Position Sensors

9-axis IMU

CPU

8 core ARM A76 , 2.4 GHz, Mali G52 GPU

2 core, 1.6 GHz

Built in Chip Computing

Depth Map Computing, 3D Scanning, Photogrammetric Computing, Point Cloud Processing and Editing

Depth Map Computing, 3D Scanning, Point Cloud Processing and Editing

Depth Map Computing

Internal Storage

256 GB

N/A

Memory (RAM)

32 GB

16 GB or 32 GB

N/A

Touchscreen Display

6 inch

N/A

Buttons

Minimum PC Requirements*

macOSCPU: M1 Pro or better; RAM ≥ 8GBWindowsCPU: Intel i7 12th or better; RAM ≥ 16GB

macOSCPU: M1 Pro or better; RAM ≥ 8GB Windows CPU: Intel i7 12th or better; RAM ≥ 16GB

Recommended PC Requirements*

macOSCPU: M3 or better; RAM ≥ 8GBWindowsCPU: Intel i9 11th or better; RAM ≥ 32GB

macOSCPU: M3 or better; RAM ≥ 8GB Windows CPU: Intel i9 11th or better; RAM ≥ 32GB

Mobile Requirements

N/A

① Android System Version: 9.0 or better; RAM ≥ 8 GB; Storage ≥ 128 GB ② iPhone Models after iPhone X; System Version: iOS 14.0 or better; RAM > 4 GB; Storage ≥ 64 GB ③ iPad 10th generation iPad or later

Compatible Operating Systems

Windows 10/11 (64-bit), macOS 11.0 or better

Windows 10/11 (64-bit), Android, iOS, macOS 11.0 or better

Native System

Android

N/A

Output File Formats

PLY, OBJ, STL, ASC, 3MF, GLTF, FBX

Ready to Print 3D Models

✔

Wi-Fi

Bluetooth

4.1

Connector Type

USB Type-C

Power Requirements

DC 7-11V, 5ASupport 65-watt Fast Charging

DC 7-11V, 5A Support 65-watt Fast Charging

DC 5V, 1A

Battery

Internal 5000 mAH

N/A

Scanner Weight

750g

750 g

190 g

Dimensions (L x W x H)

200 x 50 x 110 mm

200 × 50 × 110 mm

153 × 45 × 29 mm

Special Object Scanning

Use scanning spray for transparent, dark, or highly reflective objects.

User Recalibration

Yes

Supported Accessories

Large Turntable, Dual-axis Turntable, Large Calibration Board for MIRACO, Power Bank Kit，Photogrammetric Metrology Kit

Large Turntable, Dual-axis Turntable, Large Calibration Board for MIRACO, Power Bank Kit

Large Turntable, Dual-axis Turntable, Handheld Stabilizer, Power Bank, Mobile Kit

Note:
1. Precision is how close repeated measurements of the same object are to each other. Accuracy is how close a measured value is to the actual (true) value. They were both acquired in a controlled lab environment. Actual results might vary, subject to the operation environment.
2. Class 1 Laser: Avoid direct eye exposure for extended periods! Refer to Standards for Class 1 Lasers for details.
3. Outdoor scans should avoid direct sunlight.
4. Some products have flashing lights, which may not be suitable for people with photosensitive epilepsy.
5. The MIRACO series 3D scanners require no PC when scanning. But the PC requirements above should be followed if you connect the MIRACO to Revo Scan (PC) for more operations.
